Medium-voltage Indoor Ground Switch Earth Switch

Purchase Quality Medium-voltage Indoor Ground Switch Earth Switch by Wzonpa Manufacturer from China

As a professional supplier in China, Wzonpa presents the JN22-40.5/31.5 Medium-voltage Indoor Ground Switch Earth Switch, engineered to provide essential grounding protection in 35kV indoor switchgear systems. Built with precision, durability, and strict compliance with IEC 62271-102, it ensures safe discharge of residual voltage and enhances operational safety in modern power distribution environments.

Product Type & Function

The Medium-voltage Indoor Ground Switch Earth Switch is a critical safety device designed to ground de-energized circuits in medium-voltage systems.

Ensures safe maintenance by discharging residual current

Prevents accidental energization through interlocking mechanisms

Acts as a protective barrier for both personnel and equipment

Product Applications

The Medium-voltage Indoor Ground Switch Earth Switch is widely applied in medium-voltage power distribution systems where safety and reliability are critical.

1. Installed in 35kV indoor switchgear within substations to ensure safe grounding during maintenance

2. Used in industrial plants where the Medium-voltage Indoor Ground Switch Earth Switch protects equipment from residual voltage risks

3. Applied in power plant auxiliary systems to maintain operational safety and stability

4. Integrated into renewable energy projects such as solar and wind substations, where it ensures safe system isolation

5. Suitable for commercial and infrastructure projects requiring continuous and secure power distribution

Core Advantages

1.Advanced Safety Engineering

Mechanical interlock system prevents incorrect operation

Guarantees grounding only when circuit is fully isolated

Minimizes operational risks and enhances worker safety

2.High Performance Under Fault Conditions

Withstands up to 31.5kA short-time current

Strong peak withstand capability ensures system stability

Reliable protection during unexpected electrical faults

3.Durable and Corrosion-Resistant Design

High-quality conductive materials reduce heat generation

Corrosion-resistant structure extends service life

Suitable for long-term indoor operation with minimal maintenance

4.Compact and Installation-Friendly

Space-saving design fits modern switchgear systems

Flexible installation with left-hand or right-hand operation

Easy integration into existing electrical infrastructure

Working Principle

The Medium-voltage Indoor Ground Switch Earth Switch operates by directly connecting the circuit to ground once power is disconnected.

Residual voltage is discharged safely

Mechanical interlock ensures zero-risk activation

Provides a secure environment for inspection and maintenance

Order Guidance

What to Provide?

Product model and rated voltage

Short-time withstand current

Phase spacing and installation direction

Custom Requirements

Optional manual operation direction

Auxiliary components and indication systems

Special specifications available upon request

Choosing the Medium-voltage Indoor Ground Switch Earth Switch means investing in safety, reliability, and long-term performance. It brings confidence to engineers, protection to workers, and stability to critical power systems—ensuring every operation is secure and every connection is trusted. Get a quote now!

Appearance and installation dimensions

Technical parameters

FAQ

Q1: What is the main role of a Medium-voltage Indoor Ground Switch Earth Switch?

It ensures electrical safety by grounding de-energized circuits, eliminating residual voltage and protecting maintenance personnel.

Q2: Why is a mechanical interlock important?

The interlock prevents operation unless the circuit is fully disconnected, reducing human error and avoiding dangerous accidents.

Q3: Where is this grounding switch typically installed?

It is commonly installed in 35kV indoor switchgear systems within substations, industrial facilities, and energy projects.

Q4: How does this product improve system reliability?

By handling high fault currents and maintaining stable grounding performance, it protects equipment and ensures continuous safe operation.

Products show
